Seven Segment Multiplexed Display Module CC

Multiplexed seven segment displays are perfect for low cost numerical output. They can be used is variety of devices like clocks, timers, counters, meters etc. They are very efficient and uses minimum number of i/o pins.

Specifications

• 4 digits.
• Digit height : 0.4 inches (approx 1cm)
• Module height : 0.5 inches
• LED colour: RED
• Type : Common Cathode

Datasheet

• Pin configuration.
• Tutorial and source code for AVR Microcontrollers.
• Tutorial and source code for PIC Microcontrollers.
