20x4 Character LCD Module Blue Backlight

SKU SKU00209

Weight 100.00 grams

Our price: Rs460.00 ($9.66)

Quantity

Ask a question about this product

Standard 20x4 Character LCD Module with blue backlight. These modules are based on standard HD44780 controller. Easy to connect with MCUs. Supports 4 or 8 bit data transfer. Can display 4 lines of 20 characters.

Exciting tutorial for using these displays with AVR MCUs.
http://extremeelectronics.co.in/avr-tutorials/using-lcd-module-with-avrs/
Exciting tutorial for using these displays with PIC MCUs.
http://extremeelectronics.co.in/microchip-pic-tutorials/interfacing-lcd-modules-with-pic-microcontrollers/

PIN Configuration.

Number	1	2	3	4	5	6	7	8	9	10	11	12	13	14	15	16
Name	GND	5v	CON	RS	R/W	E	DB0	DB1	DB2	DB3	DB4	DB5	DB6	DB7	LED+	LED-
